● Adopting Cummins engines, offering cutting-edge design, dependable performance and long service life;
● Alloy steel crankshaft and connecting rod, ensuring high durability;
● Continuous operation with high combustion efficiency and low fuel consumption;
● PT pump fuel injection technology, guaranteeing safe and reliable operation;
● Anti-vibration units are optimally designed, while the pressure boosting system and low-speed cooling fan enable the noise level to be significantly lowered;
● Generator excitation system allows the generator set to recover the voltage in the event of a sudden load, guaranteeing the reliability of operation.
| 50HZ | ||||||
| Genset Model | Standby Power | Prime Power | Engine Model | Dimension(MM)L*W*H | ||
| KVA | KW | KVA | KW | |||
| KC-C30 | 30 | 24 | 27 | 22 | 4B3.9-G2 | 1800*850*1300 |
| KC-C44 | 44 | 35 | 40 | 32 | 4BT3.9-G2 | 1800*900*1400 |
| KC-C69 | 69 | 55 | 62.5 | 50 | 4BTA3.9-G2 | 1800*900*1400 |
| KC-C70 | 70 | 56 | 65 | 52 | 4BTA3.9-G2 | 1800*900*1400 |
| KC-C90 | 90 | 72 | 80 | 64 | 4BTA3.9-G11 | 1900*800*1400 |
| KC-C110A | 110 | 88 | 100 | 80 | 4BTA3.9-G13 | 1900*800*1400 |
| KC-C110B | 110 | 88 | 100 | 80 | 6BT5.9-G2 | 2200*900*1450 |
| KC-C125 | 125 | 100 | 113 | 90 | 6BT5.9-G2 | 2200*900*1450 |
| KC-C138 | 138 | 110 | 125 | 100 | 6BTA5.9-G2 | 2300*900*1450 |
| KC-C150 | 150 | 120 | 138 | 110 | 6BTAA5.9-G2 | 2350*1000*1550 |
| KC-C175 | 175 | 140 | 160 | 128 | 6BTAA5.9-G12 | 2500*1000*1550 |
| KC-C200 | 200 | 160 | 180 | 145 | 6CTA8.3-G2 | 2500*900*1560 |
| KC-C215 | 215 | 172 | 200 | 160 | 6CTAA8.3-G2 | 2600*900*1560 |
| KC-C264 | 264 | 211 | 250 | 200 | 6LTAA8.9-G2 | 2600*1000*1600 |
| KC-C275 | 275 | 220 | 250 | 200 | 6LTAA8.9-G3 | 2600*1000*1600 |
| KC-C300 | 300 | 240 | 270 | 220 | 6LTAA9.5-G3 | 2700*1100*1700 |
| KC-C313 | 313 | 250 | 275 | 220 | NTA855-G1A | 2600*1600*1500 |
| KC-C340A | 340 | 272 | 313 | 250 | 6LTAA9.5-G1 | 2700*1100*1700 |
| KC-C340B | 340 | 272 | 313 | 250 | NTA855-G1B | 3000*1100*1700 |
| KC-C375 | 375 | 300 | 350 | 280 | NTA855-G2A | 3000*1100*1700 |
| KC-C388 | 388 | 310 | 350 | 280 | NTA855-G4 | 3000*1100*1700 |
| KC-C413 | 413 | 330 | 375 | 300 | NTAA855-G7 | 3300*1250*1850 |
| KC-C425 | 425 | 340 | 388 | 310 | 6ZTAA13-G3 | 3000*1300*1700 |
| KC-C438 | 438 | 350 | 400 | 320 | QSNT-G3 | 2900*1250*1900 |
| KC-C475 | 475 | 380 | 438 | 350 | 6ZTAA13-G4 | 3000*1300*1800 |
| KC-C500 | 500 | 400 | 450 | 360 | KTA19-G3 | 3400*1400*1900 |
| KC-C513 | 513 | 410 | 500 | 400 | QSZ13-G3 | 3100*1250*1850 |
| KC-C550 | 550 | 440 | 500 | 400 | QSZ13-G10 | 3300*1450*1900 |
| KC-C563A | 563 | 450 | 500 | 400 | KTA19-G3A | 3400*1400*2000 |
| KC-C563B | 563 | 450 | 500 | 400 | KTA19-G4 | 3400*1450*2000 |
| KC-C625 | 625 | 500 | 563 | 450 | KTAA19-G5 | 3600*1460*2100 |
| KC-C688 | 688 | 550 | KTAA19-G6A | 3700*1500*2200 | ||
| KC-C800 | 800 | 640 | 725 | 580 | KT38-GA | 4450*1700*2360 |
| KC-C825 | 825 | 660 | 750 | 600 | KTA38-G2 | 4450*1700*2360 |
| KC-C888 | 888 | 710 | 800 | 640 | KTA38-G2B | 4450*1700*2360 |
| KC-C1000 | 1000 | 800 | 910 | 728 | KTA38-G2A | 4450*1700*2360 |
| KC-C1100 | 1100 | 880 | 1000 | 800 | KTA38-G5 | 4400*1800*2400 |
| KC-C1250 | 1250 | 1000 | KTA38-G9 | 4800*1800*2500 | ||
| KC-C1375 | 1375 | 1100 | 1250 | 1000 | KTA50-G3 | 5200*2000*2500 |
| KC-C1650 | 1650 | 1320 | 1375 | 1100 | KTA50-G8 | 5900*2270*2500 |
| KC-C1875 | 1875 | 1500 | 1675 | 1340 | KTA50-G15X | 6200*2300*2550 |
| KC-C2090 | 2090 | 1650 | 2000 | 1600 | KTA50-G16B | 6200*2300*2550 |
| 60HZ | ||||||
| Genset Model | Standby Power | Prime Power | Engine Model | Dimension(MM)L*W*H | ||
| KVA | KW | KVA | KW | |||
| KC-CU28 | 28 | 22 | 25 | 20 | 4B3.9-G11 | 1900*800*1400 |
| KC-CU35 | 35 | 28 | 30 | 25 | 4B3.9-G2 | 1800*850*1300 |
| KC-CU38 | 38 | 30 | 35 | 28 | 4B3.9-G12 | 1800*900*1300 |
| KC-CU50 | 50 | 40 | 45 | 36 | 4BT3.9-G2 | 1800*900*1400 |
| KC-CU70 | 70 | 56 | 64 | 51 | 4BTA3.9-G2 | 1800*900*1400 |
| KC-CU88 | 88 | 70 | 75 | 60 | 4BTA3.9-G2 | 1800*900*1400 |
| KC-CU100 | 100 | 80 | 90 | 72 | 4BTA3.9-G11 | 1900*800*1400 |
| KC-CU115 | 115 | 92 | 105 | 84 | 6BT5.9-G2 | 2200*900*1450 |
| KC-CU138 | 138 | 110 | 125 | 100 | 6BT5.9-G2 | 2200*900*1450 |
| KC-CU145 | 145 | 116 | 131 | 105 | 6BTA5.9-G2 | 2300*900*1450 |
| KC-CU165 | 165 | 130 | 150 | 120 | 6BTAA5.9-G2 | 2350*1000*1550 |
| KC-CU175 | 175 | 140 | 160 | 128 | 6BTAA5.9-G12 | 2500*1000*1550 |
| KC-CU209 | 209 | 167 | 190 | 152 | 6CTA8.3-G2 | 2500*900*1560 |
| KC-CU230 | 230 | 184 | 210 | 168 | 6CTAA8.3-G2 | 2600*900*1560 |
| KC-CU275 | 275 | 220 | NT855-GA | 2600*1600*1500 | ||
| KC-CU285 | 285 | 228 | 260 | 208 | 6LTAA8.9-G2 | 2600*1000*1600 |
| KC-CU313 | 313 | 250 | 288 | 230 | 6LTAA8.9-G3 | 2600*1000*1600 |
| KC-CU325 | 325 | 260 | 285 | 230 | 6LTAA9.5-G3 | 2700*1100*1700 |
| KC-CU350A | 350 | 280 | 325 | 260 | 6LTAA9.5-G1 | 2700*1100*1700 |
| KC-CU350B | 350 | 280 | 313 | 250 | NTA855-G1 | 3000*1100*1700 |
| KC-CU375 | 375 | 300 | 350 | 280 | NTA855-G1B | 3000*1100*1700 |
| KC-CU425 | 425 | 340 | 388 | 310 | 6ZTAA13-G3 | 2900*1200*1700 |
| KC-CU438A | 438 | 350 | 394 | 315 | NTA855-G3 | 3000*1100*1700 |
| KC-CU438B | 438 | 350 | 400 | 320 | QSNT-G3 | 2900*1250*1900 |
| KC-CU475 | 475 | 380 | 438 | 350 | 6ZTAA13-G2 | 2900*1200*1700 |
| KC-CU525 | 525 | 420 | 500 | 400 | QSZ13-G3 | 3100*1250*1850 |
| KC-CU550 | 550 | 440 | 500 | 410 | KTA19-G3 | 3400*1400*1900 |
| KC-CU625 | 625 | 500 | 560 | 450 | QSZ13-G11 | 3100*1250*1850 |
| KC-CU625A | 625 | 500 | 563 | 450 | KTA19-G3A | 3400*1400*2000 |
| KC-CU625B | 625 | 500 | 563 | 450 | KTA19-G4 | 3400*1450*2000 |
| KC-CU688 | 688 | 550 | 588 | 470 | KTAA19-G5 | 3580*1555*2150 |
| KC-CU713 | 713 | 570 | 625 | 500 | QSK19-G4 | 3800*1600*2200 |
| KC-CU750A | 750 | 600 | KTAA19-G6A | 3700*1500*2200 | ||
| KC-CU750B | 750 | 600 | 688 | 550 | QSK19-G5 | 3800*1550*2200 |
| KC-CU844 | 844 | 680 | 775 | 620 | KT38-G | 4450*1700*2360 |
| KC-CU963 | 963 | 770 | 875 | 700 | KTA38-G1 | 4450*1700*2360 |
| KC-CU1000 | 1000 | 800 | 906 | 725 | KTA38-G2 | 4450*1700*2360 |
| KC-CU1038 | 1038 | 830 | 938 | 750 | KTA38-G2B | 4450*1700*2360 |
| KC-CU1125 | 1125 | 900 | 1000 | 800 | KTA38-G2A | 4450*1700*2360 |
| KC-CU1250 | 1250 | 1000 | 1125 | 900 | KTA38-G4 | 4400*1800*2400 |
| KC-CU1375 | 1375 | 1100 | KTA38-G9 | 4800*1800*2400 | ||
| KC-CU1438 | 1438 | 1150 | 1200 | 960 | QSK38-G5 | 4800*1800*2400 |
| KC-CU1550 | 1550 | 1240 | 1375 | 1100 | QSK38-G4 | 5300*2000*2500 |
| KC-CU1563 | 1563 | 1250 | 1375 | 1100 | KTA50-G3 | 5200*2000*2500 |
| KC-CU1875 | 1875 | 1500 | 1575 | 1260 | KTA50-G9 | 5900*2300*2500 |
Are you trading company or manufacturer ?
We are factory.
What is your power range of your diesel generator?
We can provide power from 8KVA-4000KVA and comprehensive power solutions for you
How long is your delivery time?
4-6 weeks.
What's your MOQ?
1 set.
What is your terms of payment ?
T/T 30% in advance and TT 70% balance paid before shipment.
What is your warranty period?
Our warranty period is 1 year or 1000 running hours whichever comes first. But based on some special project, we can extended our warranty period.
Do you offer OEM service?
Yes.
How could I trust you?
Diesel Service & Supply stands behind the quality of all the generators and industrial power equipment we sell. If you are not convinced by the pictures, videos, check-in reports, load tests, customer experiences and sales associates’ knowledge about the generator you are interested in, then we invite you to come visit our expansive yard and shop facility to witness a load test and see the professional operation we have going on here.
After i receive the genset what should i do ?
After you got the generator, please read the operation manual carefully.
